Application

Applies to plastic films, laminated films, extrusion films, foils, sheets, rubber, paper, paperboard, wood, brake pad, tyre, windshieldwiper, conveyor belt, hare, metal, carbon rod, catheter, artificial skin etc testing of static coefficient and dynamic coefficient, especially used in food & pharmaceutical industries, quality inspection departments as well as research and development institutions.

Features

1: 2 patents and 2 counts of software copyright registration.

2: Designed based on ISO, GB standard.

3: Highly accurate load cell.

4: Test speed can be set freely through touch screen.

5: Keyboard touch screen operation.

6: Real color TFT LCD display.

7: Micro-printer built-in.

8: DB9 RS232 communication port.

9: Professional computer software support.

10: Wide range sample thickness test is available.

11: Sled mass can be set through touch screen.

12: Static coefficient, dynamic coefficient test.

13: Overload, limit position protection.

14: One touch to start a new test.

15: Various non-standard test is available.

16: Various analysis functions.

17: Low power consumption.

18: Ethernet communication module is optional.

19: LMIS system is optional(Laboratory Management Information System), easy to share test data.

Technical Indexes

Standards

GB 10006、GB/T 17200、ISO8295

Configuration

Delivery: main unit, sled 200g.

Optional: Professional computer software, communication cable, non-standard sled, calibration assemblies, LMIS system.

Note: Specifications are subject to change without prior notice.
